WLM automatic food grinding machine is made of stainless steel,it can grind sugar,salt,spice,rice,vegetables and etc. The final food powder size is adjustable,clients can get different product by changing motor rotary speed.
WLM automatic food grinding machine is made of stainless steel,it can grind sugar,salt,spice,rice,vegetables and etc. The final food powder size is adjustable,clients can get different product by changing motor rotary speed.
+86 13921209007
director@wtgrinderline.com
The automatic food grinding machine
Material enters the mill chamber via screw conveyor where it is sheared and milled by fast-rotating blades. The powder passes the guide ring and enters the classifier chamber.
Model |
WLM-10 |
WLM-15 |
WLM-20 |
WLM-30 |
WLM-60 |
WLM-80 |
WLM-100 |
Production capacity(kg) |
10~50 |
50~100 |
80~200 |
200~400 |
400~800 |
500~1000 |
600~1200 |
Feeding size(mm) |
<5 |
<10 |
<10 |
<12 |
<12 |
<12 |
<12 |
Crushing fineness(mesh) |
80-600 |
||||||
Motor power(kw) |
12 |
13.37 |
18.37 |
42.5 |
77.5 |
96 |
138 |
Spindle speed(rpm) |
4000 |
5800 |
4200 |
3800 |
3200 |
2800 |
2000 |
Weight(kg) |
500 |
1000 |
1200 |
1800 |
2500 |
3000 |
4000 |
Overall dimension (L*W*H)(mm) |
1700x1800x2200 |
4500x1250x2700 |
6000x1250x2900 |
7100x1300x3650 |
8000x2300x4500 |
8500x2500x4600 |
10000x2800x5000 |
